Descripción
AMD B550 Ryzen AM4 Gaming ATX motherboard with PCIe® 4.0, teamed power stages, Intel® 2.5Gb Ethernet, dual M.2 with heatsinks, SATA 6 Gbps, USB 3.2 Gen 2 and Aura Sync RGB
- AM4 socket_ Ready for 3rd Gen AMD Ryzen™ processors
- Best gaming connectivity_ PCIe® 4.0-ready, dual M.2, USB 3.2 Gen 2 Type-C® plus HDMI™ 2.1 and DisplayPort 1.2 output support
- Smooth networking_ Intel® 2.5Gb Ethernet with ASUS LANGuard
- Robust power solution_ Teamed power stages with ProCool power connector, high-quality alloy chokes and durable capacitors
- Renowned software_ Intuitive dashboards for UEFI BIOS and ASUS AI Networking make it easy to configure gaming builds
- DIY-friendly design_ Includes pre-mounted I/O shield, BIOS FlashBack™, Q-LEDs and SafeSlot
- Unmatched personalisation_ ASUS-exclusive Aura Sync RGB lighting, including Aura RGB header and addressable Gen 2 RGB header
- Industry-leading gaming audio_ AI Noise-Canceling Microphone, SupremeFX S1220A codec, DTS® Sound Unbound™ and Sonic Studio III for immersive audio
Designed for those seeking to get the most out of their build, ROG Strix B550 Gaming series motherboards offer a feature-set usually found in the higher-end ROG Strix X570 Gaming series, including the latest PCIe® 4.0 connectivity. Offering robust power delivery and effective cooling, ROG Strix B550-A Gaming is well-equipped to handle 3rd Gen AMD Ryzen™ CPUs. As an added bonus, outstanding performance is complemented by a stunning silver-and-white finish and cyberpunk-inspired aesthetics that present a standout look.
Audio
1 x PCIe 4.0 x16 (x16 mode)
1 x PCIe 3.0 x16 (x4 mode)
3 x PCIe 3.0 x1
Storage
6 x SATA III
2 x M.2 (2242/2260/2280/22110) – SATA & PCIe
RAID
RAID 0, 1, 10
Wireless
–
LAN
2.5GB LAN
ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A
Supports AMD 2-Way CrossFireX
USB Ports Supported
2 x USB 3.2 Gen2 (1 Type-A & 1 Type-C at back)
6 x USB 3.2 Gen1 (4 at back, 2 at mid-board)
6 x USB 2.0 (2 at back, 4 at mid-board)
Back Panel I/O Ports
1 x Intel I225-V 2.5Gb LAN
1 x DisplayPort
1 x HDMI
2 x USB 3.2 Gen2 (Type-A & C)
4 x USB 3.2 Gen1
2 x USB 2.0
1 x Optical S/PDIF out
1 x BIOS FlashBack Button
5 x Gold-plated audio jacks
Internal I/O Connectors
1 x CPU Fan
1 x CPU OPT Fan
3 x Chassis Fan
1 x AIO_PUMP
1 x AAFP
2 x Aura RGB Strip
1 x Addressable Gen2
1 x USB 3.2 Gen1
2 x USB 2.0
2 x M.2 Socket 1 with M key
6 x SATA 6Gb/s
1 x Thunderbolt
.
1 x 24-pin EATX
1 x 8-pin ATX 12V
1 x 4-pin ATX 12V
1 x System panel
1 x Thermal sensor
1 x Clear CMOS jumper
Accessories
PCI/PCI Express
Multi-GPU Support
Motherboard Type
Click for CPU support
Form Factor
ATX
Socket
AMD AM4
Chipset
AMD B550
#Hide#DDR Type
DDR4
CPU Support
RAM Technology
1 x HDMI
1 x DisplayPort
DDR4 (Dual Channel)
RAM Slots
4 x DIMM
RAM Speeds
4600(O.C)/4400(O.C)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2800/2666/2400/2133 MHz
Maximum Memory
128GB
Graphics
Integrated Graphics Processor*
Graphics specifications may vary between CPU types
Graphics Ports
4 x SATA 6Gb/s cables
1 x ROG Strix stickers
1 x Cable ties pack
1 x Extension cable for Addressable LED
1 x ROG Thank you card
1 x M.2 SSD screw package
1 x M.2 Rubber Package
